Descrizione
Descrizione del prodotto
Descrizione del prodotto Intertechnik LU55/010/140 | 0,1 mH | 0,08| 3% | 15 AWG
The I.T. Intertechnik LU55/010/140 is a high-quality air coil of 0.1mH inductance, with a resistance of 0.08 .
Highlights
- High-quality air coil with 0.1mH inductance
- Low electrical resistance of 0.08
- Exceptional tolerance of 3%
- Constructed with a reliable 15 AWG wire
Product details
I.T. Intertechnik LU55/010/140 | 0,1 mH | 0,08| 3% | 15 AWG |Air Coil
The I.T. Intertechnik LU55/010/140 air coil is a top-notch product in the category of 'Crossover components Air core coils'. The coil, having an inductance of 0.1mH and an electrical resistance of 0.08 , is designed to deliver optimal performance. The product's inductance tolerance is an impressive -3%, ensuring unwavering performance. The coil is constructed with a 15 AWG wire, promising durability and long-term usage. The coil's wire connection length is 10mm, with a tinning length of 9mm. The coil body material is ABS, adding to the product's robustness. The inductance measure is nominal at 25 degrees Celsius at 1KHz, reinforcing the coil's effective operation under different conditions.
I.T. Intertechnik article code: 1340046
