Descrizione del prodotto Intertechnik LU120/2.7/20 | 2,7 mH | 0,31| 3% | 12 AWG
High-quality 2.7mH air coil with superior inductance and low resistance
Highlights
- Exceptional inductance of 2.7mH
- Low resistance of 0.31 Ohms
- 12 AWG for robust connection
- 3% inductance tolerance for precise operation
Product details
I.T. Intertechnik LU120/2.7/20 | 2,7 mH | 0,31| 3% | 12 AWG |Air Coil
This I.T. Intertechnik LU120/2.7/20 Air Coil is a top-of-the-line crossover component designed for superior performance. With an exceptional inductance of 2.7mH, it ensures stable energy storage for your audio devices. The coil offers a low resistance of 0.31 Ohms, promoting efficient energy transmission and minimizing power loss. The coil features 12 AWG, ensuring a robust and reliable connection for your devices. With a 3% inductance tolerance, it guarantees precise operation and optimal performance. The coil's wire connection length is 10mm, with a tinning length of 9mm, and it is made from ABS material, ensuring durability and longevity. The coil's inductance measurement is nominal at 25 degrees Celsius at 1KHz, further enhancing its performance efficiency.
I.T. Intertechnik article code: 1340075
