Descrizione del prodotto Intertechnik LUT32/015/10 | 0,15 mH | 0,21| 3% | 18 AWG
High-grade air therm inductor with exceptional inductance and resistance precision.
Highlights
- Inductance value of 0.15mH
- Resistance of 0.21 Ohms
- 3% inductance tolerance
- Constructed with 18 AWG wire
Product details
I.T. Intertechnik LUT32/015/10 | 0,15 mH | 0,21| 3% | 18 AWG | Air Therm Inductor
This I.T. Intertechnik air therm inductor is a standout component in the crossover components coils air core coils category. It features an inductance value of 0.15mH and a resistance of 0.21 Ohms, delivering high precision and reliability. The 3% inductance tolerance ensures consistent performance, while the 18 AWG wire construction offers the robustness needed in a variety of applications. The inductor is made with>99.99% pure copper wire that employs thermoplastic insulation for enhanced durability. It has a wire connection length of 50 mm and a tinning length of 9 mm. The coil body material is polycarbonate, able to withstand temperatures ranging from -90 to 135 degrees Celsius. The inductor's inductance measurement is nominal at 25 degrees Celsius. This product is the epitome of high-quality design and meticulous construction, meeting the exacting requirements of modern electronic components.
I.T. Intertechnik article code: 1340604
